Client Hotkeys
Global Hotkeys
| Hotkey | Description |
|---|---|
| F2 | Opens the debug text box. This shows information about each pane (i.e., what are the chart sources). When this mode is open, press the G key to show the global evaluation graph. |
| F4 | Toggle RT (real-time) mode on or off. RT mode lets you update the dashboard as you drag the sliders. If RT mode is off, slider updates on mouse up. |
| F8 | Display / hide the frame rate. Frame rate is shown on the bottom left. RT (real-time) mode is shown on the bottom right. |
| ESC | Exits full screen |
| ESC, then R | Reset all panes zoom & pan |
| CTRL ` (tilde) | Resets all filters |
| CTRL 1 | Resets pane dimensions |
| ----- |
Geo Hotkeys
These hotkeys are effective when a geo pane is selected
| Hotkey | Description |
|---|---|
| Mouse wheel | Zoom in and out of the geo |
| Click and drag | Pan the geo |
| R or F | Reset and frame the view (to the entire map) |
| C | Centers the view |
| ALT P | Show / hide selection options. This lets you toggle selection shape or coordinate layers, and whether to select useing rectangle, circle, lasso, etc. |
| ALT L | Display layer information |
| CTRL Left or Right arrow keys | Toggle camera views |
| Double click OR CTRL click | Opens up the info PPG for a coord or shape |
| ----- |
Chart Hotkeys
These hotkeys are effective when a chart pane is selected
| Hotkey | Description |
|---|---|
| CTRL + mouse wheel | Zoom in and out of the chart |
| CTRL + right click and drag | Pan thea chart view |
| R or F | Reset and frame the view |
| C | Centers the view |
Dataframe Hotkeys
These hotkeys are effective when a dataframe pane is selected
| Hotkey | Description |
|---|---|
| Mouse over the title area, then CTRL + mouse wheel | Zoom in and out of the dataframe |
| R | Reset and frame the view |
